PMS SINGLE OUTPUT POWER SUPPLY 25W-150W
Features
- Universal AC input/full range
- PFC 0.98 @115VAC ; 0.95@230VAC
- Built in remote on off control
- Built in remote sense function
- Built in forced air cooling
- Short circuit/over load/ over voltage/over temp protection.
- Approvals: UL/CUL/TUV/CB/CE
Input voltage: 90-264VAC : 120-370VDC
DC
adjust range: -5%~ +-10% of rated voltage
Over
load protection: 115%-140% constant current, auto
recovery
Over voltage protection: 115%-140% of rated
voltage
Working
temperature: 0-50degC @100%, -10degC @80%, 60degC 60%
Safety
standards: UL 1012, UL 1950, TUV EN60950 approved
EMC
standards: EN55022 CLASS B, EN61000-3-2,3 EN61000-2
|
|
| Type No |
Output
voltage
|
Output
Amps
|
Efficiency% |
Dimensions |
| PMPSP-1000-12 |
12 |
75 |
82 |
278X129X127 |
| PMPSP-1000-13.5 |
13.5 |
67 |
82 |
278X129X127 |
| PMPSP-1000-24 |
24 |
37.6 |
84 |
278X129X127 |
| PMPSP-1000-27 |
27 |
33.6 |
80 |
278X129X127 |
| PMPSP-1000-48 |
48 |
19 |
86 |
278X129X127 |
| PMPSP-1500-12 |
12 |
112.5
|
88 |
278x129x191 |
| PMPSP-1500-13.5 |
13.5 |
100.5 |
82 |
278x129x191 |
| PMPSP-1500-24 |
24 |
56.4 |
84 |
278x129x191 |
| PMPSP-1500-27 |
27 |
50.4 |
84 |
278x129x191 |
| PMPSP-1500-48 |
48 |
28.5 |
86 |
278x129x191 |
|
|
|
|
|
|
